Vibratory Screening Machine

Product description

The rotary vibrating screen is a universal high-precision screening equipment with a compact size and flexible mobility. The outlet angle can be freely adjusted. It supports customization of special models such as ultrasonic, gates, and flanges. It is wear-resistant and durable, capable of continuous automated production. It can efficiently process various dry and wet materials for fine screening and is a standard screening equipment for powder processing production lines.

Working principle
The vertical vibration motor's upper and lower eccentric blocks rotate to generate three-dimensional excitation force, which drives the screen body to vibrate in a circular motion. The materials enter from the center and spread along the screen surface. Fine particles pass through the screen while coarse particles are discharged from the outer ring. The angle of the heavy hammer can be adjusted to control the screening effect.

Features & Benefits

1. Three-dimensional rotary vibration, with high screening accuracy, capable of reaching 500 mesh.
2. 304/316 stainless steel, fully sealed without dust.
3. Multiple layers can be stacked, allowing for multi-level sorting at once.
4. Quick net replacement, low noise, and small footprint.
5. Adjustable discharge angle, suitable for both dry and wet powder slurry.

Product parameter

Production line diagram

1. Vacuum feeding into the mixer, automated, dust-free
2. The mixed materials directly enter the sieve machine for screening

Detail display

Application
